The ABB Micro Power-Shield Type 607 is a secondary injection test set specifically designed to test the Micro-Power Shield (MPS-C) solid state trip systems used in ABB low voltage AC power circuit breakers.
Here’s a breakdown of its key features:
Trip Unit:
Function:
Benefits:
Technical Specifications:
Resources:
Trip Unit:
- MPS-C-3, MPS-C-3G
- MPS-C-4, MPS-C-4G
- MPS-C-5, MPS-C-5G
Function:
- Tests threshold currents and time delays on long-time, short-time, and ground functions of the MPS-C trip system.
- Determines threshold currents on the instantaneous element.
- Checks the internal toroid board of the MPS-C.
Benefits:
- Portable and self-contained:Â Comes with permanently attached connecting cables stored within the case for convenient testing.
- Easy to use:Â Simple operation with straightforward instructions.
- Comprehensive testing:Â Provides thorough testing of all critical MPS-C functions.
- Reliable:Â Ensures accurate and consistent test results.
Technical Specifications:
- Model:Â Type 607
- Application:Â Testing ABB Micro Power-Shield (MPS-C) trip systems
- Type:Â Secondary injection test set
- Features: Tests long-time, short-time, ground functions, instantaneous element, and toroid board
- Portability:Â Self-contained with built-in cables
- Ease of use:Â Simple operation
- Testing:Â Comprehensive and reliable
