The Raytech WR14 is a battery-powered, two-channel winding resistance meter designed for measuring the DC resistance of all types of magnetic windings safely and accurately. It can test transformers, rotating machine windings, and perform low-current resistance measurements on connections, contacts, and control circuits.
Specifications:
Key Features:
Accessories:
Resources:
Specifications:
- Size: L: 470 mm (18.5″) W: 357 mm (14.1″) H: 176 mm (6.9″)
- Weight: 9.6 kg (21.1 lbs.)
- Input Power: 88 to 264 VAC, 47…63 Hz, or 12V DC (charging only)
- Output Voltage: 0 to 30V DC
- Test Current: User Selectable: 25mA … 15A
- Display: Color LCD with a back light and a touch screen
- Front Panel: Sealed, anodized
- Interface: 2 USB 2.0 (1 host, 1 device) and 9 Pin RS-232 serial
- Memory Storage: Internally stores more than 10,000 test results
- Temperature: Operating: –10°C to 60°C (14ºF to 140ºF), Storage: –20°C to 70°C (-4ºF to 158ºF)
- Battery Duration: 200 single measurements at 15A
Key Features:
- Pure, filtered DC power source for the highest accuracy readings
- Highest Accuracy and Precision of any high current test system
- Complete, automatic calibration system and system diagnostics
- Charges inductive loads up to 1,500 Henry
- High power DC supply (15A / 30V)
- 2 independent measuring channels
- Automatic measurements of resistance from 0.00 µΩ … 100 kΩ
- Demagnetizing Circuit (Advanced design)
- Microprocessor-based system with internal storage for over 10,000 test results
- Temperature channels with automatic resistance correction
Accessories:
- 2043N-05018: Current Cable Positive – 10m (32 ft.)
- 2043N-05019: Current Cable Negative – 10m (32 ft.)
- 2043N-05007: Potential Cables CH 1 Positive – 10m (32 ft.)
- 2043N-05008: Potential Cables CH 1 Negative – 10m (32 ft.)
- 2043N-05009: Potential Cables CH 2 Positive – 10m (32 ft.)
- 2043N-05010: Potential Cables CH 2 Negative – 10m (32 ft.)
- 2043N-05020: Jumper Cable – 10m (32 ft.)
- 1002A-07001: Power Cord – 6.09m (20 ft.)
- 2040A-05009: Ground Lead – 10m (32 ft.)
- 1004A-27003: External USB Drive
- 2040A-08003: Touch Screen Stylus
- 2042A-03001: External Zippered Pouch
- 1002A-03002: Cable Bag with Shoulder Strap
- 1003A-37001: A-B USB Cable – 3m (10 ft.)
- 2040X-18002: Paper Refill for Printer – 5 rolls
- 2043A-02001: Instruction Manual
- 2043X-10001: Certificate of Accuracy
