The Schneider Electric Square D CBTMB is a versatile module used with UTS & CBTU1 Universal Test Sets for testing and diagnosing Square D circuit breakers equipped with various electronic trip units.
The “B” in CBTMB doesn’t indicate a specific trip unit type like the models you mentioned previously. Instead, it refers to the Micrologic Series B trip units.
Here’s a breakdown of the CBTMB’s key features and functions:
Function:
- Communication bridge: It enables interaction between the UTS and Micrologic Series B trip units, allowing for comprehensive testing and analysis of the circuit breaker performance.
- Trip unit functionalities:
- Reading and verifying trip settings
- Analyzing trip history data
- Performing functional tests like time delay measurements
- Identifying potential issues requiring maintenance
Compatibility:
- UTS Universal Test Sets:Â Works with all UTS models.
- Micrologic Series B trip units:Â Compatible with various Square D circuit breaker models equipped with these trip units.
Features:
- Compact and portable:Â Easy to carry and use in field applications.
- Rugged construction:Â Built to withstand demanding field conditions.
- Easy connections:Â Straightforward setup with clear labels and color-coded cables.
- Reliable performance:Â Ensures accurate test results and reliable diagnoses.
Applications:
- Testing and commissioning Square D circuit breakers with Micrologic Series B trip units.
- Verifying trip settings and ensuring proper operation.
- Troubleshooting circuit breaker malfunctions and identifying potential problems.
- Maintaining the reliability and safety of electrical systems.
