The Schneider Electric LV485510SP is a service interface module designed for use with Pact series circuit breakers. It’s essentially a tool for professionals in electrical testing and maintenance.
Compatible Circuit Breakers:
Compatible Trip Units:
Key Functions:
Benefits:
Various Factors:
Resources:
Compatible Circuit Breakers:
The LV485510SP can be used with the following Schneider Electric circuit breaker ranges:
- Masterpact NT/NW (MicroLogic)
- EasyPact MVS
- ComPacT NS
- PowerPacT P- and R-frame
- ComPacT NSX
- PowerPacT H-, J-, and L-frame
Compatible Trip Units:
To determine the correct trip units for your specific application, you’ll need to consider the following:
- Circuit breaker frame size: This will limit the range of available trip units.
- Nominal current rating: The trip unit must be rated for the desired current carrying capacity.
- Required protection functions: Choose trip units with the necessary protection features (e.g., thermal magnetic, electronic, motor protection).
- Specific application requirements: Consider any additional features or customization options available for the trip units.
Key Functions:
- Compatibility: Works with various Schneider Electric circuit breakers, including Masterpact and ComPact series.
- Ease of Use: Intuitive connection to MicroLogic trip units and support for auxiliary devices.
- Accuracy and Reliability: Offers precise testing and configuration for maintaining electrical safety and operational integrity.
Benefits:
- Enhanced Efficiency: Streamlines electrical testing and configuration processes.
- Improved Safety: Helps ensure the safe operation of electrical systems.
- Optimized Performance: Enables accurate assessment and maintenance of circuit breakers.
Various Factors:
Each of these circuit breaker ranges uses specific trip units. The choice of trip unit depends on various factors including:
- Nominal current rating
- Type of protection required (overcurrent, short circuit, earth fault, etc.)
- Specific application and customer needs
