The Schneider Electric Square D CBTM3 ME-NE-PE Module is an adapter specific to UTS & CBTU1 Universal Test Sets (UTS) used for testing and diagnosing Square D circuit breakers equipped with ME-NE-PE trip units.
Here’s a breakdown of its key features and functions:
Functions:
Features:
Compatibility:
Applications:
Functions:
- Enables communication between the UTS & CBTU1 and ME-NE-PE trip units, allowing for comprehensive testing and analysis of the circuit breaker performance.
- Provides access to various functionalities of the trip unit, including:
- Reading and verifying trip settings
- Analyzing trip history data
- Performing functional tests like time delay measurements
- Identifying potential issues requiring maintenance
Features:
- Compact and portable:Â Easy to carry and use in field applications.
- Rugged construction:Â Built to withstand demanding field conditions.
- Simple connections:Â Clearly labeled and color-coded cables for straightforward setup.
- Reliable performance:Â Ensures accurate test results and reliable diagnoses.
Compatibility:
- Designed specifically for UTS & CBTU1 Universal Test Sets and Square D ME-NE-PE trip units.
- Not compatible with other test sets or trip unit types.
Applications:
- Testing and commissioning Square D circuit breakers with ME-NE-PE trip units.
- Verifying trip settings and ensuring proper operation.
- Troubleshooting circuit breaker malfunctions and identifying potential problems.
- Maintaining the reliability and safety of electrical systems.
