The Raytech TR-1P is a portable, single-phase transformer turns ratio meter. It’s designed for on-site testing of power, potential, and current transformers.
The TR-1P is a valuable tool for anyone involved in transformer testing and maintenance. Its portability, accuracy, and built-in printer make it a convenient and efficient solution for on-site testing.
Here’s a breakdown of its key features and functions:
What it does:
Key Features:
Benefits:
Applications:
Resources:
What it does:
- Measures Turns Ratio: The TR-1P accurately determines the ratio of primary to secondary turns in a transformer. This is essential for assessing the transformer’s condition and ensuring it’s operating correctly.
- Built-in Printer: The “P” in TR-1P signifies that it has an integrated printer, allowing you to generate test reports immediately in the field.
- Automatic Operation: It simplifies testing with automated features, reducing the need for manual adjustments and calculations.
- Wide Ratio Range: Can test transformers with ratios up to 4000:1.
- Portable and Rugged: Designed for field use, it’s lightweight and housed in a durable, waterproof case.
Key Features:
- High Accuracy: Provides precise turns ratio measurements.
- Easy-to-Read Display: Features a clear LCD screen for displaying test results.
- Battery Operated: Allows for convenient on-site testing without needing a power source.
- Advanced Protection: Includes built-in protection mechanisms to prevent damage to the instrument and the transformer under test.
- Data Storage: Can store test results for later analysis.
Benefits:
- Improved Efficiency: Automates the testing process, saving time and effort.
- Reduced Errors: Minimizes the risk of human error in measurements and calculations.
- On-Site Printing: Provides immediate documentation of test results.
- Enhanced Safety: Includes safety features to protect the operator and equipment.
Applications:
The Raytech TR-1P is used for testing transformers in various settings, including:
- Power substations
- Industrial plants
- Electrical utilities
- Maintenance and repair facilities
